Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
| Processor manufacturer |
Intel |
| Processor socket |
LGA 1700 |
| Compatible processor series |
Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| Supported processor sockets |
LGA 1700 |
| Maximum internal memory supported by processor |
128 GB |
| Supported memory types |
DDR4-SDRAM |
| Number of memory slots |
4 |
| Memory slots type |
DIMM |
| Memory channels |
Dual-channel |
| ECC сompatibility |
ECC & Non-ECC |
| Supported memory clock speeds |
2133,2400,2666,2933,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000,4133,4266,4300,4400,4500,4600,4700,4800,4933,5000,5133,5333 MHz |
| Supported memory clock speed (max) |
5333 MHz |
| Maximum internal memory |
128 GB |
| Supported memory module capacities |
1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB |
| Unbuffered memory |
Yes |
| Supported storage drive types |
HDD & SSD |
| Supported storage drive interfaces |
M.2, SATA III |
| Number of HDDs supported |
4 |
| Number of storage drives supported |
6 |
| RAID support |
Yes |
| RAID levels |
0, 1, 5, 10 |
| Parallel processing technology support |
Not supported |
| Maximum resolution |
4096 x 2304 pixels |
| HDCP |
Yes |
| DirectX version |
12.0 |
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
1 |
| Number of SATA III connectors |
4 |
| Total number of SATA connectors |
4 |
| Number of Parallel ATA connectors |
1 |
| S/PDIF out connector |
Yes |
| Audio connector |
Yes |
| Front panel audio connector |
Yes |
| Front panel connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| Power fan connector |
Yes |
| CPU fan connector |
Yes |
| Number of chassis fan connectors |
3 |
| EPS power connector (8-pin) |
Yes |
| TPM connector |
Yes |
| Parallel connector |
Yes |
| Serial port headers |
1 |
| 12V power connector |
Yes |
| RGB LED pin header |
Yes |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| Ethernet LAN (RJ-45) ports |
1 |
| PS/2 ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| DisplayPorts quantity |
2 |
| DisplayPort version |
1.4 |
| Headphone outputs |
1 |
| Line-in |
Yes |
| Microphone in |
Yes |
| Digital audio optical out |
3 |
| USB connector type |
USB Type-A |
| Ethernet LAN |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Wi-Fi |
No |
| Motherboard chipset |
Intel B760 Express |
| Audio output channels |
7.1 channels |
| Product colour |
Brown |
| PC health monitoring |
Fan, Temperature, Voltage, Water cooling |
| Component for |
PC |
| Motherboard form factor |
micro ATX |
| Motherboard chipset family |
Intel |
| Power source type |
ATX |
| Windows operating systems supported |
Windows 10, Windows 11 |
| PCI Express x1 slots |
1 |
| PCI Express x1 (Gen 3.x) slots |
1 |
| PCI Express x4 slots |
1 |
| PCI Express x16 slots |
1 |
| PCI Express x16 (Gen 3.x) slots |
1 |
| PCI Express x16 (Gen 4.x) slots |
1 |
| Number of M.2 (M) slots |
2 |
| BIOS type |
UEFI AMI |
| BIOS memory size |
128 Mbit |
| ACPI version |
5.0 |
| Clear CMOS jumper |
Yes |
| Desktop Management Interface (DMI) version |
2.7 |
| System Management BIOS (SMBIOS) version |
2.7 |
| Country of origin |
China |
| Products per shipping (inner) case |
1 pc(s) |
| Battery weight |
3 g |
| Lithium weight per battery |
0.07 g |
| Number of battery cells |
1 |
| Battery technology |
Lithium-Manganese Dioxide (LiMnO2) |
| Battery type |
CR2032 |
| Package width |
265 mm |
| Package depth |
265 mm |
| Package height |
54 mm |
| Package weight |
990 g |
| Width |
244 mm |
| Depth |
244 mm |
| Height |
35 mm |
| Batteries included |
Yes |
| Bundled software |
Norton Internet Security |
| Warranty period |
3 year(s) |
